Rittal KX Terminal box, sheet steel, 150 x 150 x 120mm Part number 1500.000

This carbon steel terminal box provides IP66 and NEMA 4 protection. It features a mini cam lock and is suitable for flexible interior installation without a gland plate, ensuring secure component housing.
Vendor: Rittal
Rubicon Industrial Technology is an authorised South African distributor for Rittal.
Availability: Out Of Stock
Product type: Control Panel
Please hurry! Only 0 left in stock
Description
Description
x
This carbon steel terminal box provides IP66 and NEMA 4 protection. It features a mini cam lock and is suitable for flexible interior installation without a gland plate, ensuring secure component housing.
Specifications
Specifications
x
Model No.KX 1500.000
Material - HousingCarbon steel
Material - CoverCarbon steel, all-round foamed-in PU seal
Surface FinishDipcoat primed, powder-coated on the outside, textured paint
ColorRAL 7035
Protection category NEMANEMA 1, 3R, 4, 12
Protection category IP to EN 60IP 66
Type rating according to UL 50EType 1, 3R, 4, 12
IK codeIK08
Dimensions - Width150 mm
Dimensions - Height150 mm
Dimensions - Depth120 mm
Material Thickness - Cover1.25 mm (0.05 in)
Material Thickness - Enclosure1.25 mm (0.05 in)
Base MaterialCarbon steel
Weight/Packaging Unit1.44 kg (3.2 lb)
Customs Tariff Number84879090
EAN4028177816145
E-Number SwedenE3465180
ETIM 7.0EC000261
ECLASS 8.027180101
ApprovalsBureau Veritas DNV-GL, Lloyds Register of Shipping, UL + C-UL (listed)
Documents
Documents
x
Download Datasheet
