Murr Profinet push pull RJ45, male 0° , 4-pole
Murr Profinet push pull RJ45, male 0° , 4-pole

Murr Profinet push pull RJ45, male 0° , 4-pole Part number 7000-74041-0000000

Murrelektronik Push Pull RJ45 male 0° IDC. 4-pol., 0,14 - 0,34mm², 4,5 - 11mm, shielded, CAT5. View full specifications on Murrelektronik | Download datasheet
Vendor: Murrelektronik
Availability: In stock
Product type: Field Sensing & Connectivity
Please hurry! Only 20 left in stock
Description
Description
x

Murrelektronik Push Pull RJ45 male 0° IDC. 4-pol., 0,14 - 0,34mm², 4,5 - 11mm, shielded, CAT5.

View full specifications on Murrelektronik | Download datasheet

Specifications
Specifications
x
IP RatingIP65 / IP67
Tariff85366990
GTIN4048879363372
Compliance/CertificationsIEC 61076-3-117 V.14
Temperature: Operating / Dynamic-40°C to 70°C
Cable Diameter (mm)4.5mm - 11mm
Packaging Size1 pc(s)
Weight (g)94g
Conductor Cross-section0,14 ... 0,34mm²
Connection TypeRJ45 / Male Straight / 4 Pole
Connection StyleIDC Terminals
Data Transmission Rate100 Mbits/s
Operating Voltage 60 VDC
Current Rating / Rated Current2 A
Documents
Documents
x
Download Datasheet
