Murr Pneumatic module,-female/male, 3-pole Part number 70MH-MAP10-0030000

Product Overview

Pneumatic module (SKU: 70MH-MAP10-0030000) designed for industrial automation and pneumatic system applications. This 3-pole female and male pneumatic module features multiple internal hose diameter options for flexible pneumatic connections as part of the Modlink Heavy modular connector system in demanding industrial environments.

Key Features

• 3-pole pneumatic module with female and male connections
• Multiple internal hose diameter options: 1.6mm, 3mm, and 4mm
• Compatible with Modlink Heavy modular connector system
• Robust construction suitable for industrial pneumatic applications
• Modular design allows flexible system configuration
• Requires mounting clips for proper installation
• Reliable pneumatic connections for automated systems

Technical Specifications

• Module Type: Pneumatic female and male, 3-pole
• Internal Hose Diameters: 1.6mm, 3mm, and 4mm options
• Pole Configuration: 3-pole design
• Connection Type: Female and male pneumatic couplings
• Required Accessories: 2× clip 70MH-ZZ100-0000000 for mounting
• Operating Pressure: Industrial pneumatic system compatible
• Material: Industrial grade materials for pneumatic applications

Applications

• Industrial automation pneumatic systems
• Manufacturing equipment pneumatic connections
• Machine tool pneumatic interfaces
• Process control pneumatic distribution
• Automated assembly line pneumatic connections
• Modular pneumatic system installations

Installation Requirements

• Requires 2× mounting clips (70MH-ZZ100-0000000) for proper installation
• Compatible with Modlink Heavy housing systems
• Modular system allows multiple modules in single housing
• Technical data guaranteed when used with Murrelektronik components

Compliance & Standards

• Industrial grade construction for demanding pneumatic applications
• Compatible with Modlink Heavy connector system
• Reliable performance when used with genuine Murrelektronik components
• Suitable for automated industrial pneumatic systems

Download existing graphical data for this product:

Product Datasheet
