Murr MSCON-D connector Female 90° Solder 19p M23

Product Overview

The Murrelektronik MSCON-D field-wireable connector provides space-saving high-density connectivity for advanced industrial automation applications requiring on-site cable termination. This M23 female 90° angled connector features a 19-pole configuration with solder connections, allowing flexible field installation with user-supplied cables for comprehensive signal transmission applications in space-constrained environments.

Key Features

• M23 female 90° angled connector with 19-pole configuration
• Field-wireable design with solder connections for on-site installation
• MSCON-D series for space-saving high-density signal transmission
• Right-angle design for panel-mounted and confined space applications
• User-configurable cable length based on application requirements
• Professional solder termination for reliable connections
• Robust M23 housing for demanding industrial environments

Technical Specifications

• Article Number: 7000-23361-0000000
• Connector Type: M23 female 90° angled, field-wireable, MSCON-D
• Number of Poles: 19-pole configuration
• Connection Method: Solder connections
• Voltage Rating: Standard industrial signal voltages
• Protection Rating: IP67 when properly installed and mated
• Housing Material: Plastic with chemical and oil resistance
• Series: MSCON-D field-wireable connector

Applications

• Space-constrained custom cable length high-density signal connections
• Panel-mounted industrial automation systems with M23 interface requirements and space limitations
• Machine control applications requiring comprehensive signal transmission with right-angle field termination
• Process control equipment with multiple input/output requirements in confined spaces
• Distribution box connections requiring 19-pole connectivity with angled orientation
• Retrofit installations where pre-assembled cables cannot accommodate space limitations

Standards and Compliance

• Quality Standards: German engineering and manufacturing
• Environmental Protection: IP67 rating for industrial environments
• Material Standards: CFC-free, cadmium-free, silicone-free, lead-free construction

Benefits

• 90° angled design saves space and prevents cable interference in tight installations
• Field-wireable design reduces inventory requirements for multiple cable lengths
• 19-pole configuration provides comprehensive connectivity for complex applications
• Solder connections ensure reliable, permanent terminations
• M23 housing provides robust protection for demanding environments
• On-site termination capability reduces installation time and complexity

Downloads

• Product Data Sheet
