Murr Miro TR Opto-coupler, screw, 5VDC, 2A

Product Overview

The Murrelektronik MIRO TR 5VDC SK is a specialized low-voltage transistor-based optocoupler module designed for 5VDC logic control applications. This module provides high-current DC switching capability up to 2A at 48VDC output, controlled by low-voltage 5.5VDC input signals. The device features ultra-compact 6.2mm width design with screw terminal connections, making it ideal for interfacing low-voltage control systems with higher-power DC loads requiring galvanic isolation.

Key Features

• Low-voltage 5VDC logic control input compatibility
• High switching capacity: 2A continuous output current
• Low input voltage: 5.5VDC maximum for logic level control
• High output capability: up to 48VDC switching
• Ultra-compact 6.2mm width for space-efficient installation
• Transistor-based optocoupler technology
• Screw terminal connections for secure wiring
• Galvanic isolation between input and output circuits

Technical Specifications

• Model: MIRO TR 5VDC SK Optocoupler Module
• Article Number: 52502
• Input Voltage: 5.5VDC maximum
• Output Voltage: 48VDC maximum
• Output Current: 2A continuous maximum
• Control Voltage: 5VDC logic level
• Module Width: 6.2mm
• Connection Type: Screw terminals
• Switching Element: Photo-transistor

Electrical Characteristics

• Control Input: 5.5VDC maximum for logic compatibility
• Load Output: Up to 48VDC, 2A switching capability
• Switching Technology: Photo-transistor optocoupler
• Output Type: Transistor switching output
• Logic Compatibility: 5VDC logic level operation
• Isolation Type: Galvanic isolation between circuits

Standards and Compliance

• Industrial Standards: Designed for industrial automation applications
• Safety Standards: Galvanic isolation for electrical safety
• Quality Standards: Murrelektronik industrial quality and reliability
• DIN Rail Standards: Standard DIN rail mounting compatibility
• Environmental Standards: Industrial environmental protection ratings

Applications

• Microcontroller and 5V logic system interfaces
• Low-voltage control of high-current DC loads
• Digital logic to power switching applications
• Embedded system output expansion
• 5V logic level industrial control interfaces
• Microprocessor-controlled DC switching systems

Installation Features

• Ultra-Compact Design: 6.2mm width maximizes cabinet space
• DIN Rail Mounting: Standard industrial mounting capability
• Screw Terminals: Secure and reliable wiring connections
• Logic Level Interface: Direct 5V system compatibility
• Professional Integration: Standard industrial module format

Benefits

• Enables direct interface between 5VDC logic systems and high-current DC loads up to 2A
• Provides complete galvanic isolation between low-voltage control and high-power switching circuits
• Features ultra-compact 6.2mm width design for maximum control cabinet space efficiency
• Offers seamless integration with microcontrollers, PLCs, and digital control systems
• Supports reliable industrial automation with secure screw terminals and professional-grade construction

Download existing graphical data for this product:

• Product Specification Sheet
