Murr M12 male 0°/female 0°, straight, yellow, 4-pole, 1m

Product Overview

The Murrelektronik M12 connection cable is designed for industrial automation signal transmission applications. This pre-assembled cable features M12 male straight connector to M12 female straight connector configuration with A-coding, providing reliable signal connections for sensors, actuators, and other industrial devices. The 1-meter PUR cable offers excellent flexibility with drag chain capability and UL/CSA certification for demanding automation applications.

Key Features

• M12 male straight to M12 female straight connector configuration
• A-coded connectors for standardized signal applications
• 1-meter PUR cable with superior flexibility
• 4x0.34mm² conductor specification for signal transmission
• UL/CSA certification for North American compliance
• Drag chain capability for dynamic applications
• Black cable jacket for professional appearance
• IP67 protection rating for harsh environments
• Optimized for industrial signal connectivity
• Pre-assembled construction for immediate installation

Technical Specifications

• Article Number: 7000-40021-0340100
• Connector Type: M12 male straight to M12 female straight
• Coding: A-coded
• Cable Length: 1 meter
• Conductor Specification: 4x0.34mm² (#22 AWG)
• Cable Type: PUR (Polyurethane), black jacket
• Protection Rating: IP67
• Certification: UL/CSA approved
• Features: Drag chain capable
• Application Category: Signal transmission and connectivity

Applications

• Industrial sensor signal transmission and extension
• Actuator control signal connectivity
• Machine automation signal distribution
• Process control signal routing applications
• Factory automation installations requiring flexible signal cables
• Robotic system signal connections with dynamic movement requirements
• Custom automation projects requiring certified signal cables
• Industrial equipment signal interface connections

Standards and Compliance

• Certification: UL/CSA approved for North American markets
• Protection Standard: IP67 rating for dust and water resistance
• Drag Chain Standards: Certified for dynamic flex applications
• Quality Standards: German engineering and manufacturing
• Safety Standards: Compliant with industrial automation requirements
• Connection Standards: M12 A-coded for standardized compatibility

Benefits

• Pre-assembled construction eliminates field termination requirements
• A-coded configuration ensures proper connection orientation
• PUR cable provides superior flexibility for dynamic applications
• UL/CSA certification ensures North American compliance
• IP67 rating protects against environmental contamination
• Drag chain capability enables use in moving automation applications
• Optimized conductor size for efficient signal transmission
• Professional black jacket appearance suitable for visible installations

Download existing graphical data for this product:

• Data Sheet
