Murr M12 male 0°, D-code / RJ45 male 0°, shielded, green, 15m

Product Overview

Industrial Ethernet extension cable (SKU: 7000-44711-7941500) featuring M12 male straight connector to RJ45 male straight connector with D-coding. This high-quality shielded cable assembly bridges industrial M12 networks to standard Ethernet infrastructure, providing reliable data transmission in demanding environments.

Key Features

• M12 male connector (0° straight) to RJ45 male connector (0° straight)
• D-coded for Industrial Ethernet applications
• SF/UTP (Screened Foiled/Unshielded Twisted Pair) shielded construction
• PUR cable jacket for superior durability and chemical resistance
• UL/CSA certified for North American installations
• IP67 protection rating on M12 connector when mated
• Green cable color for easy network identification

Technical Specifications

• Connector Type: M12 x 1 threaded (male) to RJ45 8P8C (male)
• Coding: D-coded (4-pole Industrial Ethernet)
• Cable Length: 15.0 meters
• Wire Configuration: 1 x 4 x AWG22 shielded
• Wire Gauge: AWG22 stranded copper conductors
• Cable Type: PUR (Polyurethane) jacketed
• Shielding: SF/UTP construction with foil and braid shield
• Operating Voltage: 60V DC maximum (30V DC UL listed)
• Operating Current: 1.5A maximum per contact at 20°C
• Operating Temperature: -25°C to +80°C
• Protection Rating: IP67 (M12 connector when mated)

Transmission Characteristics

• Category 5e / ISO Class D compliance
• Data Rate: 100 Mbit/s
• Transmission Protocol: Industrial Ethernet, EtherNet/IP, EtherCAT, ProfiNet
• Rated Surge Voltage: 1.0 kV
• Impedance: 100 Ohm ±15%

Applications Perfect for connecting Industrial Ethernet devices to standard network infrastructure:

• Machine control system integration
• Industrial automation networks to IT infrastructure
• Sensor and actuator communication networks
• Factory floor to office network connections
• Process control system networking
• Robotic system integration

Compliance & Standards

• UL Listed - Communications & Data cable assemblies
• CSA certified for Canadian installations
• Category 5e Ethernet performance standards
• RoHS compliant
• Resistant to welding sparks and industrial chemicals

Download existing graphical data for this product:

Product Datasheet
