Murr M12 female 90°, A-code with cable, 5-pole, violet, 5m

Product Overview

The Murrelektronik M12 female 90° connector with pre-assembled shielded data cable features a 5-pole A-coded configuration specifically designed for DeviceNet and CANopen industrial communication applications. This ready-to-use cable assembly includes a 5-meter PUR shielded cable with specialized AWG24+22 conductor configuration and open-ended wires for direct connection to control systems, providing robust connectivity in industrial automation environments where reliable data transmission and space-saving angled connections are essential.

Key Features

• M12 female 90° angled connector with A-coding and 5-pole configuration
• Pre-assembled 5-meter shielded PUR data cable with open-ended wires
• Specialized for DeviceNet and CANopen communication protocols
• AWG24+22 conductor configuration optimized for data transmission
• Space-saving right-angle design for confined installation spaces
• EMI protection through integrated cable shielding
• UL/CSA certified cable construction
• Drag chain compatible design for dynamic applications
• Violet cable jacket for data cable identification
• Ready-to-use assembly eliminates field termination time

Technical Specifications

• Article Number: 7000-13251-8030500
• Connector Type: M12 female 90° angled, A-coded
• Cable Length: 5 meters
• Cable Type: PUR (Polyurethane) jacket, shielded
• Conductor Configuration: AWG24+22 (specialized data cable)
• Pole Configuration: 5-pole
• Communication Protocols: DeviceNet, CANopen compatible
• Operating Temperature: Standard industrial range
• Protection Rating: IP67 at connector interface
• Cable Color: Violet (data cable standard)
• Certification: UL/CSA approved

Applications

• DeviceNet network connections requiring space-saving angled connectors
• CANopen communication systems with confined installation spaces
• Industrial data networks requiring EMI protection and signal integrity
• Control cabinet connections to field devices with right-angle cable routing
• Process control applications requiring reliable data transmission
• Manufacturing automation systems with space constraints
• Machine installations requiring drag chain compatible data cables
• Direct connection to PLCs, controllers, and communication modules

Standards and Compliance

• Protection Standards: IP67 rated connector interface
• Cable Certification: UL/CSA approved construction
• Communication Standards: DeviceNet and CANopen compatible
• Quality Standards: German engineering and manufacturing
• Performance Standards: Designed for harsh industrial conditions with data integrity

Benefits

• Pre-assembled design eliminates field termination time and potential errors
• 90° angled design saves valuable installation space and improves cable management
• Specialized AWG24+22 conductor configuration optimized for data communication
• DeviceNet and CANopen compatibility ensures protocol compliance
• Integrated shielding provides superior EMI protection for data integrity
• Drag chain compatibility enables use in dynamic applications
• UL/CSA certification ensures compliance with North American standards
• Robust PUR jacket withstands chemicals, oils, and environmental contaminants
• 5-meter length ideal for extended cabinet-to-field device connections
• Violet cable jacket provides easy identification as data cable
• Open-ended wires provide flexibility for various termination methods
• Ready-to-use assembly reduces installation time and labor costs
• Right-angle design prevents cable kinking and extends cable life

Downloads:

• Product Data Sheet
