Murr M12 female 0° with cable, straight, 4-pole, yellow, 20m

Product Overview

The Murrelektronik M12 female straight connector is a pre-assembled cordset designed for industrial sensor and actuator connectivity applications requiring socket-type connections. This A-coded signal connector features a 5-meter PVC cable with 4x0.34mm² conductors, terminated with open-ended wires for direct connection to control systems. Rated for signal applications with UL/CSA certification and distinctive yellow cable jacket, it provides reliable connectivity in industrial automation environments where visual identification is important.

Key Features

• M12 female straight (0°) connector with A-coding for signal applications
• 5-meter PVC cable with distinctive yellow jacket for easy identification
• 4x0.34mm² conductors optimized for signal transmission
• UL/CSA certification for North American applications
• Gold-plated contacts ensuring optimum conductivity
• Yellow cable jacket for enhanced visibility and safety identification
• Open-ended wire termination with cable sleeves for flexible connections
• 100% tested during manufacturing process for highest quality and reliability

Technical Specifications

• Article Number: 7000-12221-0140500
• Connector Type: M12 female straight (0°), A-coded
• Cable Length: 5 meters
• Conductor Specification: 4x0.34mm² PVC cable
• Voltage Rating: Signal applications
• Current Rating: 4A maximum
• Cable Type: PVC (Polyvinyl Chloride), yellow
• Contact Material: Gold-plated for optimum conductivity
• Protection Rating: IP67 when mated

Applications

• Industrial sensor and actuator socket connections
• Machine control signal reception and distribution
• Process control applications requiring female connector interfaces
• Factory automation sensor networks with color-coded identification systems
• Equipment requiring socket-type connections for easy sensor replacement
• Control panel and junction box applications where visual identification is critical

Standards and Compliance

• Certification: UL/CSA approved for North American markets
• Quality Standards: German engineering and manufacturing
• Protection Standards: Industrial-grade environmental protection with IP67 rating

Benefits

• Pre-assembled construction eliminates field termination errors
• Female connector design enables easy sensor and actuator connection/disconnection
• PVC cable provides cost-effective solution for standard applications
• Vibration-resistant design with union nut vibration protection
• Gold-plated contacts ensure long-term reliable connectivity
• Yellow cable jacket enhances visibility for safety and maintenance identification
• Resistance to oils and cooling lubricants for industrial environments
• Cable sleeves included for professional installation
• Plastic housings with good resistance against chemicals and oils
• Ideal for applications requiring socket connections with visual identification

Download existing graphical data for this product:

• Data Sheet
