Product Overview
The Murrelektronik M12 female straight connector provides reliable signal transmission for advanced industrial automation applications requiring high pin count connectivity with electromagnetic interference protection. This A-coded connector features a 12-pole shielded configuration with a 5-meter PVC cable and open-ended wires, delivering cost-effective connectivity with enhanced signal integrity for complex transmission applications.
Key Features
Technical Specifications
Applications
Standards and Compliance
Benefits
Downloads
IP Rating / Detailed | IP65 |
Tariff | 85444290 |
GTIN | 4048880000000.0 |
ETIM | EC001855 |
Temperature: Operating Min | -25.0°C |
Temperature: Operating Max | 85.0°C |
Stripping Length (mm) | 80.0mm |
Thread | M12 |
Tightening Torque | 0 |
Nominal Voltage | 125.0 |
Interface | no |
Mounting Type | inserted |
Current load capacity | to |
Current Rating / Rated Current | 1.0 |
Packaging size / unit | 1 |
Material: Housing / Grip | contact |
Material: Jacket / Cover Nut | PUR |
Material: Sensing Surface / Contacts | gold |
Material: Wire Insulation | Polyolefin |
Material: Gasket | FKM |
Material: Screw / connection | Zinc |
Communication | M12 |
Stranding | 4 |
Bending radius (fixed) | 8.0 |
Bending radius (dynamic) | 10.0 |
Operating Voltage Max | 30.0 |
