Murr M12 female 0°, A-code with cable, 5-pole, 5m

Product Overview

The Murrelektronik M12 female straight connector is a pre-assembled cordset with 5-meter PUR cable and 5x0.34mm² conductors. This A-coded signal connector features drag chain capability and UL/CSA certification for reliable connectivity in demanding industrial automation environments requiring 5-pole socket connections.

Key Features

• M12 female straight (0°) connector with A-coding, 5-pole
• 5-meter PUR cable with drag chain capability
• 5x0.34mm² conductors for multi-signal transmission
• UL/CSA certification for North American applications
• Gold-plated contacts for optimum conductivity
• Black cable with open-ended wire termination
• 100% tested during manufacturing

Technical Specifications

• Article Number: 7000-12241-6350500
• Connector Type: M12 female straight (0°), A-coded, 5-pole
• Cable Length: 5 meters
• Conductor Specification: 5x0.34mm² PUR cable
• Voltage Rating: 125V signal applications
• Current Rating: 4A maximum
• Cable Type: PUR (Polyurethane), black with drag chain capability
• Protection Rating: IP67 when mated

Applications

• 5-pole industrial sensor and actuator socket connections
• Multi-signal machine control reception in moving applications
• Advanced sensor connectivity requiring power and multiple signal lines
• Factory automation networks with expanded I/O requirements
• Robotics and automated equipment requiring 5-pole socket connectivity

Standards and Compliance

• Certification: UL/CSA approved for North American markets
• Drag Chain Standards: Certified for dynamic flex applications
• Quality Standards: German engineering and manufacturing

Benefits

• Pre-assembled construction eliminates field termination errors
• 5-pole female design enables advanced sensor connection/disconnection
• PUR cable provides superior flexibility and chemical resistance
• Drag chain capability for moving machinery applications
• High resistance against abrasion, oils, and UV exposure
• Ideal for sensors requiring both power and multiple signal connections

Download existing graphical data for this product:

• Data Sheet
