Murr M12 female 0°, A-code with cable, 4-pole, grey, 5m

Product Overview

M12 female connector with cable (SKU: 7014-12221-2140500) designed for Food & Beverage applications in industrial automation systems. This A-coded 4-pole connector features M12 female straight (0°) design with 5 meters of gray PVC cable with open-ended wires for flexible sensor and actuator connections requiring custom terminations.

Key Features

• M12 female straight (0°) A-coded connector for standardized connections
• 5-meter gray PVC cable with open-ended wires for custom terminations
• 4-pole configuration with 4 × 0.34mm² conductors
• Food & Beverage industry compliant design
• UL/CSA certified construction for North American markets
• Stainless steel housing for hygienic applications
• Open wire ends allow flexible installation and custom connections
• Compatible with standard M12 A-coded male devices

Technical Specifications

• Connector: M12 female straight (0°) A-coded, 4-pole
• Cable Length: 5 meters
• Wire Configuration: 4 × 0.34mm² stranded copper
• Cable Type: PVC jacket, gray color
• Termination: Open-ended wires
• Housing Material: Stainless steel construction
• Protection Rating: IP67 (when properly mated)
• Operating Temperature: Standard industrial range

Applications

• Food & Beverage processing equipment sensor connections
• Hygienic applications requiring stainless steel connectors
• Sensor and actuator connections with custom wire terminations
• Industrial automation systems requiring A-coded interfaces
• Process control installations in food processing environments
• Equipment connections where open wire ends are preferred

Compliance & Standards

• UL/CSA certified construction
• A-coding compliant with IEC 61076-2-101 standards
• Food & Beverage industry compliant materials
• Stainless steel construction for hygienic requirements
• RoHS compliant materials

Download existing graphical data for this product:

Product Datasheet
