Murr M12 female 0°, A-code with cable, 4-pole, 20m

Product Overview

The Murrelektronik M12 female straight connector is a pre-assembled cordset designed for industrial sensor and actuator connectivity applications requiring socket-type connections. This A-coded signal connector features a 20-meter PVC cable with 4x0.34mm² conductors, terminated with open-ended wires for direct connection to control systems. Rated for signal applications with UL/CSA certification and black cable jacket, it provides reliable long-distance connectivity in extensive industrial automation environments.

Key Features

• M12 female straight (0°) connector with A-coding for signal applications
• 20-meter PVC cable with black jacket for professional appearance
• 4x0.34mm² conductors optimized for signal transmission over extended distances
• UL/CSA certification for North American applications
• Gold-plated contacts ensuring optimum conductivity
• Black cable jacket for versatile installation aesthetics
• Open-ended wire termination with cable sleeves for flexible connections
• 100% tested during manufacturing process for highest quality and reliability

Technical Specifications

• Article Number: 7000-12221-6142000
• Connector Type: M12 female straight (0°), A-coded
• Cable Length: 20 meters
• Conductor Specification: 4x0.34mm² PVC cable
• Voltage Rating: Signal applications
• Cable Type: PVC (Polyvinyl Chloride), black
• Contact Material: Gold-plated for optimum conductivity
• Protection Rating: IP67 when mated

Applications

• Long-distance industrial sensor and actuator socket connections
• Extended reach machine control signal reception and distribution
• Process control applications requiring female connector interfaces across large equipment layouts
• Factory automation sensor networks spanning extensive areas
• Equipment requiring socket-type connections for easy sensor replacement across wide installations
• Control panel and junction box applications spanning large facilities
• Distribution and connection hubs in extensive automated systems
• Material handling and conveyor systems requiring long-distance socket connections

Standards and Compliance

• Certification: UL/CSA approved for North American markets
• Quality Standards: German engineering and manufacturing
• Protection Standards: Industrial-grade environmental protection with IP67 rating

Benefits

• Pre-assembled construction eliminates field termination errors
• Female connector design enables easy sensor and actuator connection/disconnection
• PVC cable provides cost-effective solution for long-distance applications
• Vibration-resistant design with union nut vibration protection
• Gold-plated contacts ensure long-term reliable connectivity over extended distances
• Black cable jacket provides professional appearance suitable for most installations
• 20-meter length minimizes need for intermediate connections in large-scale installations
• Resistance to oils and cooling lubricants for industrial environments
• Cable sleeves included for professional installation
• Plastic housings with good resistance against chemicals and oils
• Optimal for socket connections requiring both professional appearance and extensive reach

Download existing graphical data for this product:

• Data Sheet
