Murr Lead M8 female 0°, PUR 3x0.25, black, 0.5m

Product Overview

The Murrelektronik M8 female connector cable is a pre-assembled short-length cordset designed for compact industrial sensor and actuator connectivity applications. This 0.5-meter cable features a straight M8 female connector with A-coding and 3-pole configuration, terminated with open-ended wires for direct connection to control systems. Constructed with PUR (polyurethane) jacket and rated for UL/CSA applications with drag chain capability, it provides reliable signal transmission in space-constrained installations requiring minimal cable length.

Key Features

• M8 female straight connector with A-coding (3-pole configuration)
• Compact 0.5-meter cable length with open-ended wire termination
• PUR jacket with 3x0.25mm² conductors for superior flexibility
• UL/CSA certification for North American applications
• Drag chain capability for dynamic applications
• Cable sleeves included for enhanced protection
• Black jacket color for professional appearance
• Art-No. 7005 - M8 Lite connector with plastic hexagonal screw

Technical Specifications

• Model: M8 female 0° A-cod. with cable
• Article Number: 7000-08041-6300050
• Connector Type: M8 female, straight (0°)
• Coding: A-coded
• Pole Configuration: 3-pole
• Cable Length: 0.5 meters
• Conductor Specification: 3x0.25mm² (#24AWG)

Connection Specifications

• Connector End: M8 female straight connector, A-coded
• Wire End: Open-ended flying leads with cable sleeves
• Cable Jacket: PUR (Polyurethane) black
• Conductor Size: 3x0.25mm² (3x#24AWG)
• Drag Chain Rating: UL/CSA + drag chain approved
• Connector Series: M8 Lite with plastic hexagonal screw
• Protection Rating: Industrial grade protection

Applications

• Compact sensor and actuator connectivity in tight spaces
• Short-reach industrial automation applications
• Panel-mounted devices requiring minimal cable length
• Machine control systems with space constraints
• Process control instrumentation in compact installations
• Industrial applications where cable management is critical

Standards and Compliance

• Certification: UL/CSA approved for North American markets
• Drag Chain Standards: Certified for dynamic flex applications
• Quality Standards: German engineering and manufacturing
• Industrial Standards: Suitable for demanding automation applications
• Flexibility Standards: PUR jacket provides superior bend radius performance

Benefits

• Ultra-short 0.5m length minimizes cable clutter in compact installations
• Pre-assembled construction eliminates field termination requirements
• PUR jacket offers superior flexibility and chemical resistance compared to PVC
• Female connector design enables direct sensor connection
• Drag chain capability enables use in dynamic applications
• A-coding ensures proper mating and prevents mis-connection
• Cable sleeves provide enhanced protection at wire termination

Download existing graphical data for this product:

• Product Specification Sheet
