Euchner TZ1RE024PGVABL12C-MF Safety switch Part number 078159

This is a solenoid-interlock safety switch from Euchner's TZ range, designed to prevent access to hazardous machine areas until motion has ceased. It combines guard locking with position monitoring, so the switch confirms the guard is closed and locked before permitting the associated machine function to run. Typical applications include...
Vendor: Euchner
Rubicon Industrial Technology is the exclusive South African distributor for Euchner.
Availability: In stock
Product type: Safety Automation
Please hurry! Only 2 left in stock
Description
Description
x

This is a solenoid-interlock safety switch from Euchner's TZ range, designed to prevent access to hazardous machine areas until motion has ceased. It combines guard locking with position monitoring, so the switch confirms the guard is closed and locked before permitting the associated machine function to run. Typical applications include interlocking on movable guards and doors within industrial machinery and automated production equipment.

Specifications
Specifications
x
Power consumption10 W
Rated insulation voltage Ui250 V
Rated impulse withstand voltage Uimp1.5 kV
Solenoid operating voltageAC/DC 24 V -15% ... +10%
Solenoid duty cycle100 %
Switching voltagemin. at 10 mA 12 V
Switching currentmin. at 24 V 1 mA
Approach speedmax. 20 m/min
Extraction force30 N
Actuation frequencymax. 1200 1/h
Actuating force35 N
Insertion depth52 mm
Mechanical life1 x 10⁶
Retention force10 N
Degree of protectionIP65
Ambient temperature-25 ... +80 °C
Material Contact HousingSilver alloy, gold flashed
Locking force Fmax2000 N
Locking force FZh1500 N
Guard locking principleClosed-circuit current principle
Monitoring of the guard position6 3x10 / 20 y
Monitoring of guard locking3x10⁶ / 20 y
Control of guard lockingDepending on external control of guard locking / 20 y
Overtravel4 mm
