Euchner N01K550-M Single limit switch, ball plunger Part number 084904

The N01K550-M is a single limit switch fitted with a ball plunger actuating element, used for position detection and monitoring on machinery and panels. The housing is made from anodised die-cast alloy with silver alloy, gold-flashed contacts, and the unit connects via an M12 x 1.5 connector. It carries an IP67 rating, suiting installation in environments with exposure to dust and moisture, and is rated for DC-13 2 A 24 V and AC-15 2 A 230 V utilisation categories.

Key specifications

• IP rating: IP67
• Connection: M12 x 1.5
