Description
x- Auxiliary release on the front
- With door monitoring contact
- Increased horizontal overtravel
Specifications
x| IP Rating | IP67 |
| Material: Housing Material | Reinforced thermoplastic |
| Power Consumption | 8 W |
| Part Width (mm) | 40mm |
| Part Length (mm) | 192mm |
| Weight (g) | 468g |
| Connection Type | 3 x M20 x 1.5 |
| Switching Current | DC-13 4 A 24 V / AC-15 4 A 230 V |
| Switching Voltage | min. at 24 V 1 mA |
| Extraction Force | min. at 10 mA 12 V |
| Actuating Element | 20 N |
| Solenoid Operating Voltage | 10 N |
| Supply Voltage | 24 V |
| Type of Voltage | AC / DC |
