TK1-4131CB024SM8 (Order no. 115310)

Safety Switch Details

Safety switch TK, plug connector(s) M12

Plug connector M12, 8-pin
Auxiliary release on the switch head
Without prevention of inadvertent locking position (faulty closure protection)
Guard locking pin left
Closed-circuit current principle

Description

Guard Locking Principle

Closed-circuit current (power to unlock): In a safety guard with guard locking according to the closed-circuit current principle, the guard is locked by spring force until the guard locking solenoid is supplied with current. The guard is unlocked by means of magnetic force. This is also referred to as mechanical guard locking.

Switching Element

4131	Slow-action switching contact
	Contacts for guard locking: 2 positively driven, positively driven contacts, 2 NO contacts

Technical Data

Approvals

Electrical Connection Values

Power consumption	8 W
Rated insulation voltage Ui	30 V
Rated impulse voltage Uimp	1.5 kV
Utilization category AC-15	1 A 24 V
Utilization category DC-13	1 A 24 V
Short circuit protection according to IEC 60269-1	1A gG
Solenoid operating voltage AC/DC	24 V -15% to +10%
Solenoid duty cycle	100 %
Switching voltage min. at 10 mA	12 V
Switching current min. at 24 V	1 mA
Thermal rated current Ith	1 A

Mechanical Values and Environment

Approach direction	C
Connection type	1 x Plug connector M12 (8-pin)
Number of guard lock monitoring NO contacts	1
Number of guard lock monitoring positively driven contacts	2
Actuation frequency	max. 1200 1/h
Installation orientation	any
Mechanical life	1 x 10⁶
Switching principle	Slow-action switching contact
Degree of protection	IP67
Ambient temperature	-20 to +55 °C
Material Housing	Reinforced thermoplastic
Contact	Silver alloy, gold flashed
Locking force Fmax	5000 N
Guard locking principle	Closed-circuit current principle
