Description
xThis IO-Link device module offers 16 digital PNP outputs and operates at 24 VDC. It features an IP67-rated housing and is designed for harsh industrial environments, offering excellent vibration resistance and durable nickel-plated protection.
Specifications
x| IP Rating | IP67, when threaded in |
| Compliance/Certifications | CE UKCA cULus WEEE |
| Material: Housing / Grip | Die-cast zinc / Nickel-plated |
| Material: Gasket | FKM 75 |
| Part Width (mm) | 68mm |
| Part Length (mm) | 32.4mm |
| Part Height (mm) | 181.5mm |
| Connection Type | Connection 1; M12x1 / Male / 4-pin / A-coded - Connection (supply voltage IN); 7/8" / Male / 5-pin - Connection slots 8x; M12x1 / Female / 5-pin / A-coded |
| IO-Link Process data length input / output | 16x PNP |
| Operating Voltage | 18 - 30.2 VDC |
| Rated Voltage | 24 V |
| Interface | IO-Link 1.0 |
| Mounting Type | 2-hole screw mount / M4 internal thread |
