Balluff BMF 32M-PS-C-2-S4 Magnetic field sensor, PNP Part number BMF0087

This magnetic field sensor detects the piston position in pneumatic cylinders fitted with a magnetic ring, providing a PNP normally open switching signal for control inputs. The aluminium housing suits mounting directly onto cylinder profiles, with an M12x1, 4-pin A-coded connector for straightforward panel or machine wiring. Rated IP67 and operating over -25 to 85°C, it is suited to industrial automation environments where reliable cylinder position feedback is required.

Key specifications

• IP rating: IP67
• Operating voltage: 10...30 VDC
• Connection: M12x1-Male, 4-pin, A-coded
• Output: PNP normally open (NO)
• Operating temperature: -25...85 °C
• Dimensions: 25 x 11.9 x 26 mm
