Balluff BMF 305M-PS-C-2-S49 Magnetic field sensor, PNP, NO Part number BMF008F

This magnetic field sensor detects the piston position of pneumatic cylinders fitted with a magnetic piston, providing a PNP normally open output for direct connection to a PLC or controller input. It is housed in an aluminium body with a PU sensing surface, rated IP67 for use in harsh industrial environments, and connects via an M8x1 three-pin male connector. The sensor operates from 10 to 30 VDC and mounts using the BMF 305-HW* bracket, suiting installation on standard cylinder profiles in automation and machine building applications.

Key specifications

• IP rating: IP67
• Operating voltage: 10 - 30 VDC
• Rated voltage: 24 V
• Connection: M8x1 / Male / 3-pin
• Output: PNP normally open (NO)
• Mounting: Mounting bracket BMF 305-HW*
