Description
xnan
Specifications
x| IP Rating | IP67 |
| Compliance/Certifications | CE UKCA cULus WEEE / IEC 60947-5-2 |
| Material: Housing / Grip | PBT |
| Material: Jacket / Cover Nut | PVC |
| Material: Sensing Surface / Contacts | PMMA |
| Part Length (mm) | 77mm |
| Cable Length (mm) | 2 000mm |
| Part Diameter (mm) | 18mm |
| Cable Diameter (mm) | 4mm |
| Connection Style | Cable, 2.00 m, PVC |
| Tightening Torque | 1.5 Nm |
| Rated Operating Distance (mm) | 20 000mm (adjustable) |
| Switching Output | NPN normally closed (NC) NPN normally open (NO) Pins 4-2 |
| Switching Frequency (Hz) | 250 Hz |
| Rated Insulation Voltage | 75 VDC |
| Operating Voltage | 10 - 30 VDC |
| Rated Operating Current | 100 mA |
