Description
xThis is an inductive proximity sensor with a PNP normally open output, rated for flush mounting where the sensing face sits level with surrounding metalwork. It detects targets at an operating distance of 2mm and operates on a 10-30VDC supply, drawing up to 100mA. The housing is brass with a nickel-free coating, the sensing surface is ceramic, and the unit carries an IP67 rating, making it suitable for compact installations in industrial automation panels and machinery where space is limited and washdown or contaminant exposure is a concern. Connection is via an integral 200mm cable terminating in an M8x1 male 3-pin connector.
Key specifications
- IP rating: IP67
- Operating voltage: 10 - 30 VDC
- Rated voltage: 24V
- Connection: M8x1 / Male / 3-pin
- Output: PNP normally open (NO)
- Mounting: Flush mounting
Specifications
x| IP Rating | IP67 |
| Compliance/Certifications | CE UKCA cULus WEEE / IEC 60947-5-2 |
| Material: Housing / Grip | Brass / Nickel-free coated |
| Material: Jacket / Cover Nut | Silicone |
| Material: Sensing Surface / Contacts | Ceramic |
| Size | 16x8x4.7 |
| Part Depth (mm) | 4.7mm |
| Part Width (mm) | 8mm |
| Part Length (mm) | 16mm |
| Cable Length (mm) | 200mm |
| Cable Diameter (mm) | 3.5mm |
| Connection Type | M8x1 / Male / 3-pin |
| Connection Style | Cable with connector, 0.20 m, Silicone |
| Rated Operating Distance (mm) | 2mm |
| Switching Output | PNP normally open (NO) |
| Switching Frequency (Hz) | DC -12 Voltage drop static max. 2.5 V Environmental conditions A |
| Rated Insulation Voltage | 75 VDC |
| Operating Voltage | 10 - 30 VDC |
| Rated Voltage | 24V |
| Mounting Type | Flush mounting |
| Rated Operating Current | 100 mA |
