Description
xnan
Specifications
x| IP Rating | IP67 |
| Compliance/Certifications | CE / UKCA / cULus / WEEE / IEC 60947-5-2 |
| Material: Housing / Grip | Brass / Nickel-free coated |
| Material: Jacket / Cover Nut | PUR |
| Material: Sensing Surface / Contacts | PBT |
| Size | 8x8 |
| Cable Length (mm) | 300mm |
| Cable Diameter (mm) | 3mm |
| Connection Type | M12x1 / Male / 3-pin |
| Rated Operating Distance (mm) | 2mm |
| Switching Output | PNP normally closed (NC) |
| Switching Frequency (Hz) | 3000 Hz |
| Rated Insulation Voltage | 75 VDC |
| Operating Voltage | 10 - 30 VDC |
| Rated Voltage | 24 V |
| Mounting Type | Flush mounting |
| Rated Operating Current | 200 mA |
