Description
xThis is an M18 inductive proximity sensor with a normally open switching output and a rated operating distance of 8mm, housed in a nickel-plated brass body with a PBT sensing face. It is rated IP67 and suited to flush mounting in panels or machine frames where sensing surfaces are exposed to the surrounding environment. The sensor operates across a wide voltage range (20-300 VDC / 20-250 VAC), making it suitable for both DC and AC control circuits, and connects via a 1/2"-20 UNF, 3-pin male connector.
Key specifications
- IP rating: IP67
- Operating voltage: 20 - 300 VDC / 20 - 250 VAC
- Rated voltage: 110 V
- Connection: 1/2"-20 UNF / 2A / Male / 3-pin
- Output: normally open (NO)
- Mounting: Flush mounting
Specifications
x| IP Rating | IP67 |
| Compliance/Certifications | CE cULus WEEE / IEC 60947-5-2 |
| Material: Housing / Grip | Brass / Nickel-plated |
| Material: Sensing Surface / Contacts | PBT |
| Size | M18x1 |
| Connection Type | 1/2"-20 UNF / 2A / Male / 3-pin |
| Tightening Torque | 30 Nm |
| Rated Operating Distance (mm) | 8mm |
| Switching Output | normally open (NO) |
| Switching Frequency (Hz) | 30 Hz |
| Rated Insulation Voltage | 250 VAC |
| Operating Voltage | 20 - 300 VDC / 20 - 250 VAC |
| Rated Voltage | 110 V |
| Mounting Type | Flush mounting |
| Rated Operating Current | 300 mA |
