Description
xnan
Specifications
x| IP Rating | IP68 |
| Compliance/Certifications | cULus CE UKCA WEEE / IEC 60947-5-2 |
| Material: Housing / Grip | Brass / Nickel-free coated |
| Material: Jacket / Cover Nut | PVC |
| Material: Sensing Surface / Contacts | PBT |
| Part Length (mm) | 53mm |
| Cable Length (mm) | 3 000mm |
| Part Diameter (mm) | 12mm |
| Tightening Torque | 10 Nm |
| Rated Operating Distance (mm) | 4mm |
| Switching Output | PNP normally open (NO) |
| Switching Frequency (Hz) | 2500 Hz |
| Rated Insulation Voltage | 250 VAC |
| Operating Voltage | 10 - 30 VDC |
| Rated Voltage | 24 V |
| Mounting Type | Flush mounting |
| Rated Operating Current | 200 mA |
