Description
xThis is a field-attachable connector featuring an M12x1, 5-pin, A-coded female straight connector with screw terminal connections, suited to cable diameters of 4mm to 6mm. The housing and grip are made from PA with a die-cast zinc jacket/cover nut, and the sensing surface/contacts use brass and PA, giving an IP67 rating for use in industrial environments. Rated for 125 VDC/VAC at 4 A, it is typically used to field-terminate sensor and actuator cabling in automation and control panel wiring.
Key specifications
- IP rating: IP67
- Operating voltage: 125 VDC / 125 VAC
- Connection: M12x1 / Female / Straight / 5-pin / A-coded
Specifications
x| IP Rating | IP67 |
| Compliance/Certifications | CE cURus WEEE |
| Material: Housing / Grip | PA |
| Material: Jacket / Cover Nut | Die-cast Zinc |
| Material: Sensing Surface / Contacts | Brass / PA |
| Cable Diameter (mm) | 4mm ... 6mm |
| Connection Type | M12x1 / Female / Straight / 5-pin / A-coded |
| Connection Style | Screw terminals |
| Tightening Torque | 0.6 Nm |
| Operating Voltage | 125 VDC / 125 VAC |
| Current Rating / Rated Current | 4 A |
