Siemens

Siemens Simatic S7-1500 Analog output module, 4 channel Part number 6ES7532-5HD00-0AB0

EAN / Barcode 4025515080022
Product Type Control Panel
Product Class PLC analogue I/O-module
ETIM Class PLC analogue I/O-module
Back Order
💬 Ask an Expert - Technical Support Available
✓ RoHS Declaration♻ EPD🌱 EcoTech Profile

Product Description

SIMATIC S7-1500, Analogue output module with 4 channels; 16-bit resolution; accuracy +/-0.3%; one potential group; parameterizable diagnostics; parameterizable substitute values for the outputs; calibration during runtime. Analogue output modules convert a 16-bit digital value into a current or a voltage and output this to the process. They are suitable, for example, for controlling proportional valves or small servo drives.

Module width 35 mm.

Technical Specifications

Analogue outputs configurableYes
Depth129 mm
Height147 mm
Number of analogue outputs4
Output signal configurableYes
Output, currentYes
Output, voltageYes
Resolution of the analogue outputs16 Bit
Width35 mm
Part Width16 mm
Part Height19 mm
Part Depth5 mm
Weight400 g
Country of OriginGermany
