Siemens Miniature circuit breaker, 1-pole, 230/400V 15kA, 40A Siemens
View on Siemens 📄 Datasheet
Siemens

Siemens Miniature circuit breaker, 1-pole, 230/400V 15kA, 40A Part number 5SY7140-7CC

EAN / Barcode 4001869449289
Product Type Control Panel
Product Class Miniature circuit breaker (MCB)
ETIM Class Miniature circuit breaker (MCB)
In Stock
View Full Product Details on Siemens 💬 Ask an Expert - Technical Support Available
✓ RoHS Declaration♻ EPD

Product Description

Miniature circuit breaker 230/400 V 15kA, 1-pole, C, 40 A Miniature circuit breaker SENTRON for fail-safe short-circuit and overload protection for residential and non-residential buildings and special industrial applications. Assembly and disassembly of the device without tools using a double slide. Any combination of conductors and busbars thanks to dual-chamber terminals.

Simple wiring of the infeed through the rear busbar. The 5SY miniature circuit breakers are available in 1-, 2-, 3-, 4-pole and 1+N- and 3+N-pole versions. All accessories can be used as standard for all 5SY miniature circuit breakers.

Simply safe with the protection devices from SENTRON.

Technical Specifications

Additional equipment possibleYes
Ambient temperature during operating55 °C
Article Number (Market Facing Number)5SY7140-7CC
Built-in depth70 mm
Connectable conductor cross section multi-wired35 mm²
Connectable conductor cross section solid-core35 mm²
Country of originChina
DataSheet in PDFDownload
Degree of protection (IP)IP20
EAN4001869449289
Frequency50 Hz
Lead CAS-No.7439-92-1 > 0, 1 % (w / w)
Net Weight (kg)0.160 Kg
Number of poles (total)1
Number of protected poles1
Over voltage category3
Pollution degree3
Power loss3.5 W
Product DescriptionMiniature circuit breaker 230/400 V 15kA, 1-pole, C, 40 A
Product familyNot available
Product Group3813
Product Lifecycle (PLM)PM300: Active Product
Rated current40 A
Rated impulse withstand voltage Uimp4 kV
Rated insulation voltage Ui440 V
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V25 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V25 kA
Rated voltage230 V
Release characteristicC
RoHS Conformity DateSince: 01.04.13
Voltage typeAC
WEEE (2012/19/EU) Take-Back ObligationYes
Width in number of modular spacings1
View complete specifications on Siemens
