Siemens Miniature circuit breaker, 1+N-pole, 230V, 15kA, 50A Part number 5SY7550-7CC

EAN / Barcode 4001869449470
Product Type Control Panel
Product Class Miniature circuit breaker (MCB)
ETIM Class Miniature circuit breaker (MCB)
In Stock
View Full Product Details on Siemens 💬 Ask an Expert - Technical Support Available
✓ RoHS Declaration♻ EPD

Product Description

Miniature circuit breaker 230 V 15kA, 1+N-pole, C, 50 A Miniature circuit breaker SENTRON for fail-safe short-circuit and overload protection for residential and non-residential buildings and special industrial applications. Assembly and disassembly of the device without tools using a double slide. Any combination of conductors and busbars thanks to dual-chamber terminals.

Simple wiring of the infeed through the rear busbar. The 5SY miniature circuit breakers are available in 1-, 2-, 3-, 4-pole and 1+N- and 3+N-pole versions. All accessories can be used as standard for all 5SY miniature circuit breakers.

Simply safe with the protection devices from SENTRON.

Technical Specifications

Additional equipment possibleYes
Ambient temperature during operating55 °C
Article Number (Market Facing Number)5SY7550-7CC
Built-in depth70 mm
Compliance with RoHS directiveSince: 2013.04.01
Concurrently switching neutral conductorYes
Connectable conductor cross section multi-wired0.75 mm²
Connectable conductor cross section solid-core0.75 mm²
Country of originChina
Degree of protection (IP)IP20
EAN4001869449470
eClass12
eClass14
eClass6
eClass7.1
eClass8
eClass9
ETIM7
ETIM8
ETIM9
Export Control RegulationsAL : N / ECCN : N
Frequency50 Hz
Lead CAS-No.7439-92-1 > 0, 1 % (w / w)
Metal FactorL-A-----
Net Weight (kg)0.320 Kg
Number of poles (total)2
Number of protected poles1
Over voltage category3
Packaging Quantity1
Pollution degree3
Power loss9.6 W
Product DescriptionMiniature circuit breaker 230 V 15kA, 1+N-pole, C, 50 A
Quantity Unit1 Piece
Rated current50 A
Rated impulse withstand voltage Uimp4 kV
Rated insulation voltage Ui250 V
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V20 kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V20 kA
Rated voltage230 V
Release characteristicC
UNSPSC15
Voltage typeAC
WEEE (2012/19/EU) Take-Back ObligationYes
Width in number of modular spacings2
