Siemens Key-operated switch, 2 positions, lock number SSG10 Part number 3SU1050-5BF01-0AA0

Siemens keyswitch, C, 22 mm, round, metal, shiny, lock number S-10-CG, with 2 keys, 2 switch positions O-I, latching, actuating angle 90°, 10:30h/13:30h, key removal O. Part of the SIRIUS ACT series, this key-operated switch features rugged die-cast housing and self-cleaning sliding contacts with a vertically rotating switching mechanism for high reliability and long operating life. The CES lock system provides secure switching control for industrial applications requiring controlled access.

Article Number: 3SU1050-5BF01-0AA0

Technical Specifications:

• Switch Type: Siemens CES key-operated switch
• Design: Round, flush mount
• Material: Metal, shiny finish
• Mounting Diameter: 22.3 mm
• Opening Width: 29.5 mm
• Opening Height: 61 mm
• Switch Positions: 2 positions (O-I)
• Contact Type: Latching operation (stay-put/maintained)
• Actuating Angle: 90°
• Key Positions: 10:30h/13:30h
• Key Removal: Position O (off position only)
• Lock Number: S-10-CG (CES SSG10)
• Keys Included: 2 keys
• Switching Mechanism: Vertically rotating for high reliability

Protection & Ratings:

• Protection Rating: IP67/IP69K
• NEMA Rating: 4X
• Operating Temperature: -25 to 70°C
• Storage Temperature: -40 to 80°C
• Relative Humidity: 10 to 95%

Physical Properties:

• Net Weight: 0.156 kg
• Packaging Dimensions: 30.00 x 100.00 x 30.00 mm
• EAN: 4011209948730
• Country of Origin: Czech Republic
• Packaging Quantity: 1 piece

Design Features:

• Die-Cast Housing: Rugged construction for industrial environments
• Self-Cleaning Contacts: Sliding contacts ensure reliable operation
• Vertical Rotation: High reliability switching mechanism
• Metal Construction: Durable shiny metal finish
• CES Lock System: Siemens proprietary lock technology
• Key Control: Removable key from off position for security
• Latching Operation: Maintains selected position until manually switched

Applications:

• Industrial Control Systems: Secure operation of machinery and equipment
• Process Control: Latching operation for maintained control states
• Safety Circuits: Controlled access to operational functions
• Mode Selection: Switching between different operational modes
• Equipment Control: Applications requiring more than one control option

Compliance & Environmental:

• Product Lifecycle: PM300: Active Product
• RoHS Compliance: Since 01.10.2014
• Export Control: AL: N / ECCN: N
• WEEE Take-Back Obligation: Yes
• REACH Article 33: Contains lead in concentrations higher than 0.1% w/w - suitable for intended use including disposal

Classification:

• eClass: 27-37-12-13 (versions 6, 7.1, 8, 9, 9.1, 12, 14)
• ETIM: EC000222 (versions 7, 8, 9)
• UNSPSC: 39-12-22-21
