Siemens Diazed fuse link, 500V, size DII, 2A

Product Overview

SKU 5SB211 - DIAZED fuse link 500 V for cable and line protection gG, Size DII, E27, 2A. This Siemens DIAZED fuse link provides reliable overcurrent protection for electrical installations and delivers effective protection against overload and short circuits.

Key Features & Specifications

• Electrical Ratings: 2A rated current, 500V AC rated voltage
• Size: DII (DIAZED size classification)
• Thread: E27 thread size for secure connection
• Operating Class: gG (general-purpose circuit protection) / gL (full-range line protection)
• Breaking Capacity: 50kA at 500V AC, 8kA at 500V DC at maximum voltage rating
• Color Code: Pink color gauge/cap for easy identification
• Material: Ceramic body construction for high thermal resistance

Performance Characteristics

• Temperature Range: -5°C to +40°C operating temperature
• Quick-Acting: Fast response characteristics for effective protection
• High Breaking Capacity: Capable of handling high fault currents
• Cable and Line Protection: Specifically designed for protecting cables and electrical lines
• Reliable Operation: Consistent performance in critical protection circuits
• Industrial Grade: Suitable for industrial switchgear and distribution applications

Physical Specifications

• Net Weight: 0.027 kg (27g lightweight design)
• Packaging Dimension: 25.00 x 111.00 x 51.00 mm
• Packaging Quantity: 1 Piece

Standards Compliance

• IEC 60269-3
• DIN VDE 0636

Applications

• Cable Protection: Primary application for protecting electrical cables from overcurrent
• Line Protection: Protection of electrical lines in distribution systems
• Industrial Switchgear: Protection in industrial electrical panels and switchboards
• Distribution Systems: Overcurrent protection in electrical distribution networks
• Commercial Installations: Protection in commercial electrical systems
• Low Current Applications: Ideal for protecting sensitive circuits requiring 2A protection
• General Purpose Protection: Suitable for various electrical protection applications

System Benefits

Part of the SENTRON DIAZED fuse system from Siemens, offering:

• Effective protection for personnel, equipment and plants through reliable shutdown
• Enhanced safety in overload and short circuit conditions
• Compatible with DIAZED fuse holders and accessories with E27 thread
• Proven technology for industrial and commercial applications
• Full-range device and line protection capabilities

Technical Advantages

• gG Operating Class: General-purpose protection suitable for most applications
• E27 Thread Design: Standard thread size for easy installation and replacement
• Ceramic Construction: High thermal resistance and durability
• Pink Color Coding: Easy identification for maintenance and replacement
• Quick-Acting Response: Fast protection response for sensitive applications
• High Breaking Capacity: Reliable protection against high fault currents

5SB2 Series Features

• Operating class gG for comprehensive protection
• Quick-acting characteristic for responsive protection
• Suitable for cable and conductor protection applications
• Service class gL/gG compatibility

Additional Information

• Country of Origin: Poland
• EAN: 4001869021171
• Article Number: 5SB211
• RoHS Compliance: Since: 01.06.2006
• WEEE Take-Back Obligation: Yes
