Murr M12 male 0°/female 0°, straight, 5-pole, A-coded, 5m

Product Overview

The Murrelektronik M12 connection cable features M12 male straight to M12 female straight A-coded connectors with a 5-meter PVC cable. Designed for 5-pole industrial automation signal transmission, it provides reliable connections for sensors and actuators requiring additional signal lines with UL/CSA certification for cost-effective installations.

Key Features

• M12 male straight to M12 female straight A-coded configuration
• 5-meter PVC cable for cost-effective long-distance connections
• 5x0.34mm² conductors for multi-signal transmission
• UL/CSA certified with IP67 protection rating
• Chemical and oil resistant plastic housings
• Pre-assembled for immediate installation

Technical Specifications

• Article Number: 7000-40041-6150500
• Cable Length: 5 meters
• Conductor Specification: 5x0.34mm² (#22 AWG)
• Cable Type: PVC (Polyvinyl Chloride), black jacket
• Protection Rating: IP67
• Certification: UL/CSA approved
• Pole Configuration: 5-pole

Applications

• 5-pole sensor and actuator signal transmission
• Equipment requiring additional signal lines
• Multi-signal industrial automation connections
• Process control applications with extended signal requirements
• Factory automation systems needing 5-pole connectivity

Benefits

• Pre-assembled construction eliminates field termination
• A-coded configuration ensures proper orientation
• 5-pole design supports multiple signal requirements
• Cost-effective PVC cable for stationary applications
• Extended 5-meter reach for flexible positioning

Download existing graphical data for this product:

• Data Sheet
