Cognex DataMan 280 Barcode reader, LED, red, 1D/2D, 16mm HSLL Part number DMR-280X-MAX

The Cognex DataMan 280 is a fixed-mount 1D/2D barcode reader using a red LED illumination with a 16mm HSLL lens configuration, suited to industrial identification tasks on production lines. It offers an image resolution of 1440 x 1080 pixels and applies Cognex decoding algorithms including 1DMax, 2DMax, Hotbars and PowerGrid for code reading. The unit communicates via serial or Ethernet interfaces and is powered by 24V PoE, with an IP67 rated zinc alloy and aluminium housing for use in demanding factory environments across an operating temperature range of 0°C to 40°C.

Key specifications

• IP rating: IP67
• Operating temperature: 0°C to 40°C
• Material: Zinc alloy / Aluminum
