Product Overview

Thermistor motor protection relay standard evaluation unit 22.5 mm enclosure spring-loaded terminal 2 changeover contacts Us = 24 V AC/DC manual/auto/remote RESET with ATEX approval 2 LEDs (ready/tripped) safe electrical isolation test/RESET button wire-break monitoring short-circuit monitoring non-volatile

This SIRIUS 3RN2 thermistor motor protection relay (Article Number: 3RN2013-2BA30) is a standard evaluation unit designed for comprehensive motor protection through advanced thermistor monitoring. The device features a 22.5 mm wide enclosure with spring-loaded terminals and operates on 24 V AC/DC supply voltage. It provides enhanced motor protection with multiple reset options, ATEX approval for hazardous environments, dual LED status indication, and advanced monitoring capabilities including wire-break and short-circuit detection.

Key Features

• Standard 22.5 mm width for comprehensive functionality
• Advanced thermistor evaluation for precise temperature monitoring
• 24 V AC/DC operation for versatile power supply options
• Multiple reset modes (manual/auto/remote) for flexible operation
• ATEX approval for use in hazardous environments
• Dual LED indicators (ready/tripped) for clear status display
• 2 changeover contacts for enhanced switching flexibility
• Spring-loaded terminals for secure and maintenance-free connections
• Wire-break monitoring for comprehensive system diagnostics
• Short-circuit monitoring for enhanced protection
• Non-volatile memory for reliable parameter retention
• Test/RESET button for convenient operation and testing

Technical Specifications

• Net Weight: 0.185 kg
• Packaging Dimensions: 111.00 x 130.00 x 38.00 mm
• Packaging Quantity: 1 piece
• Quantity Unit: 1 Piece
• Country of Origin: Germany
• Enclosure Width: 22.5 mm
• Supply Voltage: 24 V AC/DC
• Contact Configuration: 2 changeover contacts
• Reset Options: Manual/Auto/Remote RESET
• Terminal Type: Spring-loaded terminals
• LED Indicators: 2 LEDs (ready/tripped)
• Certifications: ATEX approval

Applications

• Hazardous area motor protection with ATEX certification
• Critical motor protection in industrial automation systems
• Temperature monitoring of electric motors and drives in demanding environments
• Process control systems requiring enhanced thermal protection
• Oil and gas industry applications requiring explosion-proof protection
• Chemical processing with motor protection in hazardous zones
• Mining operations requiring certified motor protection
• Petrochemical facilities with stringent safety requirements

Advanced Protection Features

• Comprehensive thermistor monitoring for accurate temperature detection
• Wire-break detection preventing undetected sensor failures
• Short-circuit monitoring for enhanced system protection
• Multiple reset modes for flexible recovery options
• Non-volatile memory preserving settings during power loss
• Safe electrical isolation between input and output circuits
• Test functionality for system verification and maintenance
• ATEX certification for hazardous environment compliance

Installation Benefits

• Enhanced functionality with 22.5 mm standard width
• Maintenance-free connections with spring-loaded terminals
• Clear status indication through dual LED display
• Flexible reset options for various operational requirements
• Easy testing with integrated test/reset button
• Professional appearance maintaining system aesthetics
• Reliable operation in demanding and hazardous environments

Compatibility

• Thermistor sensors for temperature monitoring
• ATEX-certified systems in hazardous environments
• Motor control systems requiring enhanced thermal protection
• Industrial control panels with advanced protection requirements
• 24 V AC/DC power systems for versatile installation
• Standard DIN rail mounting systems

Safety & Certification

• ATEX approval for use in explosive atmospheres
• Safe electrical isolation ensuring operator safety
• Wire-break monitoring preventing dangerous undetected failures
• Short-circuit protection for enhanced system safety
• Non-volatile memory ensuring consistent protection parameters
• Comprehensive diagnostics for system integrity verification

Product Classifications

• Product Lifecycle: PM300 Active Product
• eClass: 27-37-15-03 (versions 6-14)
• ETIM: EC002568 (versions 7, 8 & 9)
• UNSPSC: 39-12-22-29

Compliance & Certifications

• Export Control: AL: N / ECCN: N
• RoHS Compliance: Since 28.05.2009
• WEEE Take-Back Obligation: Yes
• ATEX Certification: Approved for hazardous environments

REACH Compliance

Information obligation imposed by Article 33, REACH Regulation: This product includes articles containing substances from the candidate list in concentrations higher than 0.1% weight by weight (w/w): Lead, Lead monoxide (lead oxide), and 6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol. Based on current information, these substances do not pose risk when used as intended, including disposal. Please refer to product documentation for additional guidance.

Download existing graphical data for this product:

For technical documentation and CAD files, please visit:

• Official Product Datasheet (PDF)
• Siemens Industry Mall Product Page
• Siemens PARTcommunity for 3D CAD Models
• Siemens Technical Support Center for technical documentation requests
