Siemens
Siemens SM1231 RTD Analog input, 4 x AI RTD module Part number 6ES7231-5PD32-0XB0
Back Order
💬
Ask an Expert - Technical Support Available
Product Description
Using the analogue input module SM 1231 RTD - 6ES7231-5PD32-0XB0 from Siemens your SIMATIC S7-1200 controller can be expanded by 4 analogue inputs. The analogue input SM 1231 processes for example Pt100 or Pt1000 resistance thermometers.
Technical Specifications
| Analogue inputs configurable | Yes |
| Appendant operation agent (Ex ia) | No |
| Appendant operation agent (Ex ib) | No |
| Depth | 75 mm |
| Height | 100 mm |
| Input signal, configurable | Yes |
| Input, current | No |
| Input, resistance thermometer | Yes |
| Input, resistor | Yes |
| Input, thermocouple | No |
| Input, voltage | No |
| Number of analogue inputs | 4 |
| Number of analogue outputs | 0 |
| Resolution of the analogue inputs | 15 Bit |
| Suitable for safety functions | No |
| Width | 45 mm |
