Siemens SM1222 Digital output, 16DO, 2A relay
Log in to view pricing
Sign in with your trade account to access live pricing and place orders. New to Rubicon Industrial Technology? Create an account in seconds.
Product Description
This digital output module for the SIMATIC S7-1200 provides 16 relay outputs rated for 2 A. It is suitable for switching both AC and DC loads and supports high switching capacity.
Additional Information
| IP Rating / Detailed | IP20 |
| Compliance/Certifications | CE / CSA / UL / cULus / FM / RCM / KC / Marine approval |
| Temperature: Operating | -20°C to 60°C (for horizontal installation) / -20°C to 50°C (for vertical installation) |
| Part Depth (mm) | 75mm |
| Part Width (mm) | 45mm |
| Part Height (mm) | 100mm |
| Weight (g) | 260g |
| Communication | |
| Supply Voltage | 20.4 to 28.8 |
| Voltage Output | 5 VDC to 30 VDC / 5 VAC to 250 VAC |
Technical Documentation & Downloads
Videos & Interactive Media
Product Media
Add Siemens videos or media manifest entries to showcase this product.
Interactive 3D CAD Model
🛠 Siemens 3D CAD Viewer Interactive
📄
Part Number: 6ES72221HH320XB0
🌐
Source: Siemens PartCommunity
📥
Downloads: STEP, DWG, 3DS, and more formats available
Tip: Use your mouse to rotate, zoom, and pan the 3D model. Click "Open Full Screen" for additional download options including STEP, DWG, 3DS, and other CAD formats.
