Siemens Simatic HMI MTP400 Unified basic panel, touch operation, 4" screen Part number 6AV2123-3DB32-0AW0

Product Overview

The Siemens SIMATIC HMI KTP400 Basic Panel 6AV2123-3DB32-0AW0 is a 4-inch widescreen TFT touch display designed for operator control and monitoring in compact automation systems. It features an integrated PROFINET interface, 16 million color display, and intuitive touch operation for efficient visualization and control. Engineered for use with WinCC Basic V13 or higher via the TIA Portal.

Key Features:

• Display: 4" widescreen TFT display with 480 × 272 resolution and 16 million colors
• Touch Technology: Resistive touch operation for accurate and durable control
• Interface: Integrated PROFINET and Ethernet connection for seamless integration
• Power Supply: 24 V DC (19.2 – 28.8 V) input range
• Front Protection: IP65 rated for use in industrial environments
• Operating System: SIMATIC WinCC Basic Runtime
• Configuration: Compatible with TIA Portal V13 or higher

Technical Specifications:

• Product Series: SIMATIC HMI Basic Panels
• Display Size: 4 inches (Widescreen)
• Resolution: 480 × 272 pixels (WQVGA)
• Colors: 16 million
• Supply Voltage: 24 V DC (19.2 – 28.8 V)
• Current Consumption: Approx. 0.16 A (typical)
• Interfaces: 1 × Ethernet (PROFINET), 1 × USB 2.0, 1 × RS422/485
• Mounting: Panel mounting with rear fixing clamps
• Dimensions: 142 mm × 116 mm × 36 mm (W × H × D)
• Weight: Approx. 0.45 kg
• Protection Class: Front IP65 / Rear IP20
• Operating Temperature: 0 °C to +50 °C
• Country of Origin: China

Product Benefits:

• Compact Design: Ideal for small machines and control panels where space is limited
• Reliable Operation: Industrial-grade protection and long lifecycle components
• Easy Integration: Seamless communication with SIMATIC controllers via PROFINET
• User-Friendly Interface: Simple configuration and operation through WinCC Basic
• Cost-Effective Solution: Combines performance, durability, and affordability
• Proven Siemens Quality: Part of the SIMATIC HMI Basic Panel family

Applications

Ideal for compact automation systems, machine-level operation, and equipment visualization in small-scale applications.
Commonly used in packaging machines, conveyors, material handling systems, and process control environments.
