Siemens Circuit breaker, 630 breaking capacity, 3-pole, 55kA

Product Overview

Circuit breaker 3VA2 IEC Frame 630 breaking capacity class M Icu=55 kA @ 415 V 3-pole, line protection ETU320, LI, In=630 A overload protection Ir=250 A...630 A short-circuit protection Ii=1.5...9x In nut keeper kit.

Article Number: 3VA2463-5HL32-0AA0

Key Features:

Electronic Trip Unit: Advanced ETU320 electronic protection system with precise digital control
Local Indication: LI feature provides on-device status indication and diagnostic information
High Current Rating: 630A nominal current capacity for heavy-duty industrial applications
Frame 630: Robust IEC Frame 630 construction optimized for high-performance applications
Breaking Capacity Class M: 55 kA breaking capacity at 415V for demanding industrial environments
Wide Adjustment Range: Extensive overload protection range from 250A to 630A for flexible application
Precision Short-Circuit Protection: Electronic short-circuit adjustment from 1.5 to 9x In for selective coordination
3-Pole Configuration: Optimized 3-pole design for three-phase power distribution systems

Technical Specifications:

Frame Size: IEC Frame 630
Pole Configuration: 3-pole
Breaking Capacity: Class M, Icu=55 kA @ 415V
Nominal Current (In): 630A
Protection System: ETU320 electronic trip unit with LI
Overload Protection: Adjustable Ir=250A...630A
Short-Circuit Protection: Adjustable Ii=1.5...9x In
Net Weight: 5.098 kg
Packaging Dimensions: 165.00 x 265.00 x 170.00 mm
Quantity Unit: 1 Piece
EAN: 4042948834121
UPC: 804766445859
Country of Origin: Czech Republic

Product Benefits:

Electronic Precision: ETU320 provides accurate, repeatable protection settings with digital reliability
Flexible Protection Settings: Wide adjustment ranges accommodate diverse load characteristics and applications
Local Diagnostics: LI feature enables on-site monitoring and troubleshooting without external devices
High Performance: 630A rating with 55 kA breaking capacity handles demanding industrial loads
Selective Coordination: Precise short-circuit adjustment (1.5-9x In) enables optimal system coordination
Advanced Protection: Electronic trip technology provides superior protection compared to thermal-magnetic units
Installation Flexibility: Wide overload range (250-630A) allows single device for multiple applications
Professional Grade: Frame 630 construction ensures reliable operation in harsh industrial environments
Cost-Effective Operation: Electronic precision reduces nuisance tripping and maintenance requirements
Future-Ready Technology: Electronic platform supports advanced monitoring and communication options

Applications: Essential protection device for high-current industrial electrical systems requiring precise electronic protection and local monitoring capabilities. Ideal for main distribution switchboards, motor control centers, industrial process equipment, power distribution panels, and critical infrastructure applications. Perfect for facilities requiring selective coordination, precise protection settings, and local diagnostic capabilities such as manufacturing plants, data centers, hospitals, commercial buildings, and industrial automation systems.
