Schneider Miniature circuit-breaker, C, 3-pole, 16A Part number A9F79316

This miniature circuit-breaker is a 3-pole device rated at 16A with a C trip curve, providing overcurrent protection for circuits within control panels. It carries an IP20 rating and is designed for fixed mounting, with single terminal connections accepting rigid or flexible conductors up to 25 mm² and 16 mm² respectively. The device operates across a temperature range of -35 to 70°C and is suitable for both AC and DC applications at 50/60 Hz.

Key specifications

• IP rating: IP20 conforming to IEC 60529
• Connection: Single terminal (top or bottom) 1…25 mm² rigid,Single terminal (top or bottom) 1…16 mm² flexible
• Operating temperature: -35…70 °C
• Colour: White
• Mounting: Fixed
