Schneider CVS100B TM32D Circuit breaker 3P3D Part number ZZA_LV510302

EASYPACT CVS 100-250 - CVS250F TM32D 3P3D This product is a moulded case circuit breaker. This range consists of all products of Easypact CVS 100-250A family: 100/160/250B, 100/160/250F and 100/160/250NA range. The environmental impacts of this referenced product are representative of the impacts of the other products of the range...
Vendor: Schneider Electric
Rubicon Industrial Technology is an authorised South African distributor for Schneider Electric.
Availability: Out Of Stock
Product type: Control Panel
Please hurry! Only 0 left in stock
Description
Description
x
EASYPACT CVS 100-250 - CVS250F TM32D 3P3D This product is a moulded case circuit breaker. This range consists of all products of Easypact CVS 100-250A family: 100/160/250B, 100/160/250F and 100/160/250NA range. The environmental impacts of this referenced product are representative of the impacts of the other products of the range which are developed with a similar technology. The main function of the Easypact CVS 100-250A product range is to protect the wires and equipment’s in the circuit by allowing Off, On and tripped operation with a service period of 20 years.
Specifications
Specifications
x
Product data sheetLV510302
[Uimp] rated impulse withstandvoltage 8 kV conforming to EN/IEC 60947-2
Network frequency50/60 Hz
Breaking capacity codeB
Mechanical durability30000 cycles
Electrical durability12000 cycles 415 V In conforming to IEC 60947-2
Control typeToggle
Thermal protection adjustmentrange 22.4…32 A
Long time pick-up adjustmenttype Ir Adjustable
Long time delay adjustmenttype Fixed
Instantaneous pick-up adjustmenttype Ii Fixed
Contact position indicatorYes
Mounting modeFixed
Mounting supportBackplate
Upside connectionFront
Dec 20, 20221
Downside connectionFront
Connections - terminalsScrew connection
Connection pitch35 mm
Compatibility codeCVS100
Width105 mm
Depth86 mm
Height161 mm
Product weight1.8 kg
StandardsIEC 60947-2 EN 60947-2
Product certificationsIEC GOST
Electrical shock protection classClass II
Pollution degree3 conforming to IEC 60664-1
IP degree of protectionIP40
Ambient air temperature for operation-25…70 °C
Ambient air temperature for storage-50…85 °C
Unit Type of Package 1PCE
Number of Units in Package 11
Package 1 Height11.500 cm
Package 1 Width14.000 cm
Package 1 Length19.000 cm
Package 1 Weight1.702 kg
