Description
xThe EasyPact CVS100B TM32D is a 4-pole moulded case circuit breaker rated at 32 A, fitted with a thermal-magnetic TM-D trip unit providing overload and short-circuit protection. It offers a rated operational voltage of 440 V AC and a breaking capacity of 25 kA at 380/415 V AC, with adjustable thermal protection between 22.4 and 32 A. Fixed-mounted with front connections and toggle control, it is intended for distribution applications within control panels.
Key specifications
- Rated voltage: 800 V AC 50/60 Hz
- Rated current: 32 A at 40°C
- Dimensions: 140 mm x 161 mm x 86 mm
Specifications
x| Product Name | EasyPact CVS100B TM32D Circuit Breaker |
| Product ID | LV510322 |
| Range | EasyPact CVS |
| Device Short Name | CVS100B |
| Product Type | Molded Case Circuit Breaker (MCCB) |
| Application | Distribution |
| Number of Poles | 4 |
| Protected Poles Description | 4D |
| Rated Current (In) | 32 A at 40°C |
| Rated Operational Voltage (Ue) | 440 V AC 50/60 Hz |
| Rated Insulation Voltage (Ui) | 800 V AC 50/60 Hz |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Breaking Capacity (Icu) | 25 kA at 380/415 V AC 50/60 Hz |
| Mounting Mode | Fixed |
| Control Type | Toggle |
| Mounting Support | Backplate |
| Connection - Upside | Front |
| Connection - Downside | Front |
| Connection Pitch | 35 mm |
| Dimensions (W x H x D) | 140 mm x 161 mm x 86 mm |
| Net Weight | 2.2 kg |
Technical Specifications
| Trip Unit Name | TM-D |
| Trip Unit Technology | Thermal-magnetic |
| Trip Unit Rating | 32 A at 40°C |
| Protection Type | Overload protection (thermal), Short-circuit protection (magnetic) |
| Thermal Protection Adjustment Range | 22.4…32 A |
| Long-time Pick-up Adjustment Type | Adjustable |
| Long-time Pick-up Adjustment Range | 0.7...1 x In |
| Long-time Delay Adjustment Type | Fixed |
| Instantaneous Pick-up Adjustment Type | Fixed |
| Instantaneous Pick-up Adjustment Range | 400 A |
| Neutral Protection Setting | 1 x Ir (4D) |
| Mechanical Durability | 30,000 cycles |
| Electrical Durability | 12,000 cycles at 415 V In |
| Utilization Category | Category A |
| Suitability for Isolation | Yes, conforming to EN/IEC 60947-2 |
| Pollution Degree | 3, conforming to IEC 60664-1 |
| IP Degree of Protection | IP40, conforming to IEC 60529 |
| Ambient Air Temperature for Operation | -25…70 °C |
| Ambient Air Temperature for Storage | -50…85 °C |
Environmental Data
| Carbon Footprint (kg CO₂ eq, Total Life Cycle) | 366 |
| Compliance | RoHS compliant |
Certifications
- EN/IEC 60947-2
- GOST
