Description
xThis circuit breaker from the EasyPact CVS100B range features a thermal-magnetic trip unit with a 63A rated current and a breaking capacity of up to 25kA at 415 VAC. It ensures reliable distribution and overload protection for AC networks.
Specifications
x| IP Rating / Detailed | IP40 |
| Compliance/Certifications | EN 60947-2,IEC 60947-2 |
| Temperature: Operating | -25…70 °C |
| Part Depth (mm) | 86mm |
| Part Width (mm) | 105mm |
| Part Height (mm) | 161mm |
| Connection Type | Screw connection |
| Max Frequency | 50/60 Hz |
| Type of Voltage | AC |
| Mounting Type | Fixed |
| Operating Period(Mech) | 30000 cycles |
| Operating Period(Elec) | 12000 cycles 415 V In conforming to IEC 60947-2 |
