Description
xThis EasyPact TVS auxiliary contact block offers 2 NO and 2 NC contacts for signalling applications. It supports control circuits with up to 690 V, providing robust performance with a mechanical durability of 10 million cycles.
Specifications
x| IP Rating | IP20 conforming to IEC 60529 |
| Country of Origin | Germany |
| Compliance/Certifications | GOST IEC 60947-5-1 |
| Temperature: Operating | -5°C to 55 °C |
| Weight (g) | 60g |
| Packaging size / unit | 1 pc(s) |
| Connection Style | 2 NO + 2 NC |
| Connection Type | Control circuit: screw clamp terminals 1 1 mm² - external diameter: 6 mm - cable stiffness: solid or flexible with cable end Control circuit: screw clamp terminals 1 1 mm² - external diameter: 6 mm - cable stiffness: solid or flexible without cable end Control circuit: screw clamp terminals 2 2.5 mm² - external diameter: 6 mm - cable stiffness: solid or flexible with cable end Control circuit: screw clamp terminals 2 2.5 mm² - external diameter: 6 mm - cable stiffness: solid or flexible without cable end |
| Rated Operating Voltage | 690 V |
| Warranty | 18 Months |
| Colour | Grey |
| RAL Code | RAL 7035 |
