Description
xSpecifications
x
| Approval | CSA, UL Listed, EAC (Eurasian), TÜV |
| Self-monitored | No |
| Min. contact current | 1 mA |
| Switch cap. E-STOP to standard | EN 60947-5-1 |
| Contact material E-STOP | AgNi |
| Ambient temperature | -30 - 85 °C |
| Pollution degree clear.&creep. | 3 |
| Connection terminal | Screw terminal |
| Net weight | 12 g |
| Gross weight | 14 g |
Environmental Data
| RoHS directive | 2011/65/EU, 2015/863/EU |
| RoHS conformity | Yes |
| RoHS exceptions | No |
| REACh compliance | Contains no SVHC substances |
| WEEE classification (08/2018) | 5 devices (feed size < 50cm) |
Commercial Data
| ECLASS version | ECLASS-13 |
| ECLASS Reference Feature | 27371302 |
| ETIM Version | ETIM-9.0 |
| ETIM Reference Group | EG000017 |
| UNSPSC 25 | 39122216 |
| GTIN | 4046548043624 |
| Harmonized System Code | 85365080 |
| Quantity per packaging unit | 1 |
Downloads
- CAD 2D drawing (PDF) - File Size: 0.1 MB, Date: 29.11.2012
- CAD 2D drawing (DXF) - File Size: 0.1 MB, Date: 29.11.2012
- CAD 3D model (STEP) - File Size: 0.3 MB, Date: 29.11.2012
- CAD 3D model (IGES) - File Size: 1.4 MB, Date: 29.11.2012
- Certificate (CSA) - File Size: 0.1 MB, Date: 08.09.2017
- Certificate (EAC) - File Size: 0.1 MB, Date: 08.09.2017
- Certificate (UL) - File Size: 0.0 MB, Date: 22.03.2018
- EU/EC-Declaration of Conformity - File Size: 0.1 MB, Date: 02.08.2023
- Operating Manual PITestop - File Size: 1.5 MB, Date: 10.10.2023
- Operating Manual PIT es Set/1 - File Size: 1.0 MB, Date: 17.07.2019
