Product Information

Name: Murr M8 Connector, female 0°, field-wireable, 3-pole
Brand: Murrelektronik
SKU: 7000-08361-0000000
Price: 0.01 ZAR
Availability: InStock

7000-08361-0000000 MURRELEKTRONIK MOSA M8 FEMALE 0° FIELD-WIREABLE (IDC)

SKU: 7000-08361-0000000

Manufacturer: MURRELEKTRONIK

Description

MOSA M8 FEMALE 0° FIELD-WIREABLE (IDC)

Product Details

Brand new product in its original packaging covered by the warranties and certifications provided by MURRELEKTRONIK
Delivery times are estimations and may vary when the item order has been processed.
You will be notified of any change to delivery times once the order has been processed.
To this delivery time, you will need to add the time of transport from our logistics centre to your company.

Technical Data

Operating voltage	max. 32 V AC/DC
Rated surge voltage	0.8 kV
Operating current per contact	max. 4 A
No. of poles	3
Configuration	fully used
Material group	IEC 60664-1, category III
Over voltage category	3
Isolation resistance	≥ 10^8 Ω
Contact resistance	≤ 10 mΩ
Connection cross section	0.25 - 0.5 mm² (conductor diameter min. 0.1 mm)
Sealing range (cable Ø)	4 - 5.1 mm
Outer wire Ø	1.2 - 1.6 mm
Locking of ports	Screw thread M8 × 1 mm, self-securing
Compression gland	Hexagonal screw/nut
Protection	IP67 inserted and tightened (EN 60529)
Wire isolation	PVC, PP, TPE
Material	TPE
Locking material	Zinc die casting, matte nickel plated
Mating cycles	≥ 100
Reconnection (cable)	10

General Data

Standards	DIN EN 61076-2-104 (M8)
Connection	Insulation displacement technology IDC
Mounting method	Inserted, tightened
Material (contact)	Brass, gold plated
Material (gasket)	FKM
Dimensions H × W × D	48×13×13 mm
Pollution Degree	3
Temperature range	-25 to 85 °C
