Compliance / Certifications | Based on VDE 0812 |
Country of Origin | Germany |
Flammability | Flame-retardant acc. to IEC 60332-1-2 |
Temperature: Operating | -5°C to 70°C |
Material: Inner Conductor / Core | Fine wire strand made of tinned-copper wires |
Material: Insulation / Inner sheath | PVC |
Material: Jacket / Outer Sheath | PVC |
Bending Radius | Flexing: 7.5 x outer diameter Fixed installation: 4 x Outer diameter |
Diameter: External conduit size (mm) | 9.1mm |
Weight | 115000g |
Peak Operating Voltage | 350 V |
Test Voltage | 1500 V |
Colour | Grey |
RAL Code | RAL 7001 |
