Harting Insert, screw, female, size 32B, c/s 0.75 - 2.5mm²

Product Overview

The Han 16E Female Insert with screw termination (17-32) is a specialized continuation insert designed for expanding connectivity in 32-position industrial connector assemblies. This female screw terminal insert features 16 contacts numbered 17-32 and is designed for use with Harting Han E Series industrial connectors. This insert works in conjunction with a standard 1-16 numbered insert to create complete 32-pole connector configurations for demanding industrial applications.

Key Features

• 16 positions with continuing marking (17-32)
• Female gender configuration for mating with corresponding male inserts
• Screw termination method for secure wire connections
• Locking clamp ensures high mechanical stability even under vibration or shock loads
• Silver-plated copper alloy contacts for optimal conductivity
• Pebble grey (RAL 7032) polycarbonate housing
• Mechanical working life of ≥500 mating cycles

Technical Specifications

• Current Rating: 16A
• Rated Voltage: 500V (600V UL/CSA)
• Conductor Cross-Section: 0.75 - 2.5 mm²
• Wire Size: AWG 18 - AWG 14
• Temperature Range: -40°C to +125°C
• Housing Size: 16B
• Series: Han E
• Contact Identification: 17-32
• Housing Material: Polycarbonate (PC)
• Contact Material: Copper alloy with silver plating
• Flammability Rating: UL 94 V-0

Installation Requirements

• Two inserts required for a complete 32-pole assembly
• The 32 pole versions require two contact inserts per connector half; a standard insert numbered 1 to 16 together with one numbered 17 to 32 insert
• Contact Screw: M3 with recommended tightening torque
• Compatible with standard Han E installation tools

Applications

Ideal for use in mechanical engineering, wind energy and other applications in tough environments. Additional applications include:

• Industrial automation systems requiring expanded I/O connectivity
• Control cabinet wiring with high contact density requirements
• Factory automation with 32-pole configurations
• Power distribution systems needing continuation numbering
• Railway and transportation applications
• Process control and monitoring systems

Compatibility

• Compatible with Size 16B hoods and housings
• Works with all Han® B series housings
• Compatible with corresponding Han E power connector components, of 6B size
• Pairs with Han 16E M insert screw (17-32) male version (09330162611) for complete connectivity
• Can be combined with standard Han E 16-position female inserts (1-16) to create 32-pole assemblies

Important Configuration

• Connectors should not be mated or unmated under electrical load
• Connectors of the same or different types arranged in a line should be polarised to prevent the possibility of wrong connection
• This is a continuation insert and must be used with a primary 1-16 numbered insert
• Proper identification and labeling of the 17-32 positions is critical for correct wiring

Certifications and Compliance

• Standards: IEC 60664-1, IEC 61984
• UL/CSA Certification: Compliant with applicable standards
• RoHS: Compliant with applicable exemptions
• ELV Status: Compliant
• Fire Protection: EN 45545-2 compliant for railway vehicles
• Country of Origin: Germany

Environmental Compliance

• Meets industrial connector environmental standards
• Suitable for use in protected electrical areas
• Compliant with international safety and environmental regulations
