Telergon Switch disconnector, size 3, 4-pole, 1250A Part number S5-12502EC0

DC Switch – disconnectors on-load , are available from 40 up to 3150A and from 900 up to 1500Vdc in 4P version. Technical Specifications: Rated Thermal Current: 1250A Poles: 4P Rated Insulated Voltage: 1500Vdc Rated Impulse Withstand Voltage: 12kV Short Circuit Current: 25kA Number of Mechanical Operations Cycles: 3000 Accessories...
Vendor: Telergon
Rubicon Industrial Technology is the exclusive South African distributor for Telergon.
Availability: Out Of Stock
Product type: Control Panel
Please hurry! Only 0 left in stock
Description
Description
x
DC Switch – disconnectors on-load , are available from 40 up to 3150A and from 900 up to 1500Vdc in 4P version. Technical Specifications: Rated Thermal Current: 1250A Poles: 4P Rated Insulated Voltage: 1500Vdc Rated Impulse Withstand Voltage: 12kV Short Circuit Current: 25kA Number of Mechanical Operations Cycles: 3000 Accessories to get IP65 Rating: DS-LI31 (Direct Handle) DS-LA31 (External Handle) Included Shaft DS-LA33 (External Handle) Without Shaft
Specifications
Specifications
x
Rated thermal current at 40°C100A, 160A, 250A, 400A
Rated insulation voltage1000Vdc
Rated operational current125A, 200A, 315A, 400A
Rated short-time withstand current20kA (peak) for 100, 150, 250, 400A
Number of mechanical operations10000, 8000, 5000 for respective ratings
Maximum weight1.9kg, 2.1kg
Documents
Documents
x
Download Datasheet
