Telergon External direct handle, size 3, 1000A Part number DCCLI31

Telergon's 1000A direct handle is designed to swiftly and effortlessly be added to the front Changeover Switches whilst in the field. The handle has an ergonomic grip, with an excellent torque/resistance balance and is IP65 rated. The DCCLI31 size is 3 and comes in standard Blue.
Vendor: Telergon
Rubicon Industrial Technology is the exclusive South African distributor for Telergon.
Availability: In stock
Product type: Control Panel
Please hurry! Only 4 left in stock
Description
Description
x

Telergon's 1000A direct handle is designed to swiftly and effortlessly be added to the front Changeover Switches whilst in the field. The handle has an ergonomic grip, with an excellent torque/resistance balance and is IP65 rated. The DCCLI31 size is 3 and comes in standard Blue.

Specifications
Specifications
x
Size1
Rated thermal current Ith200 A, 250 A, 315 A, 400 A
Rated breaking capacity600 A, 750 A, 945 A, 1200 A (400V AC22)
Rated making capacity600 A, 750 A, 945 A, 1200 A (400V AC22)
Rated insulation Ui1000 V
Rated impulse Uimp8 kV
Short-circuit making capacity Icm12 kA (peak)
Short-time withstand current Icw8 kA rms
AC Rated operational Ie Ue200 A, 250 A, 315 A, 400 A (400V AC21A)
Number of mechanical operations8000 cycles
Dimensions (mm)L: 227, 293; P: 166, 166
IP Protection classIP65
Auxiliary contacts1NO+1NC, 2NO+2NC
Maximum weight (3/4 poles) CCF4.8/5.3 kg, 5/5.5 kg
Maximum weight (3/4 poles) CCP5.3/5.9 kg, 5.5/6 kg
Dimensions (mm) Type 1L: 375, P: 166
Dimensions (mm) Type 2L: 536, P: 166
